Identification method
1：N/1：1 comparison
False accept rate（FAR）
＜0.0001 %（the highest safety level）
False reject rate（FRR）
＜0.01 %（high safety level）
Users capacity
≤100ID/300 templates
Recognition speed
＜1 second
Vein template data
single template ≤ 1K bytes template name format：FV_U(ID).xgd
Communication interface
USB2.0、UART
Working voltage
DC 5.0V（±0.5V）or DC 3.3V (±0.3V)
Working current
＜27.5mA/5V or＜27.5mA/3.3V
Standby current
＜2uA
Power management mode
capacitor induction power on, system startup time < 10mS
Working environment
temperature：-20℃～60℃ humidity：20%～80%RH
? Product features:
●The MCU of XG-V7S adopts fingerprint AS608, ARM Cortex-M core 32-bit microcontroller, and the working frequency is 144MHZ
● AS608 has rich peripherals: 1 USB2.0 full speed device interface, 2 UART interfaces, 1 voice PWM output interface
● Integrated finger vein module with the fastest speed, the lowest power consumption and the smallest volume in the world
? Function extension:
● Full duplex serial port TTL level supports extended SPI mode
● Support extended PWM voice output
? Industrial Design:
● Adopt dust-proof and waterproof design, IP65 protection grade
● The camera lens is designed with multi-mode, multi-layer and high transparent glass, which can effectively suppress distortion and stray light interference
? Product application:
● Smart lock, safe
